Mirafi S41 Virgin PP Nonwoven Geotextile 150gsm (3m x 130m Roll)

Description

• The MIRAFI®  S41 belongs to Solmax’s S-Series - a family of mechanically bonded, needle-punched nonwoven polypropylene geotextiles designed for separation, filtration, and drainage functions in road and infrastructure works.
  Manufactured from 100 % UV-stabilized continuous polypropylene filaments, S41 combines high strength, flexibility, and hydraulic stability for long-term soil reinforcement and filtration performance.

  With more than five decades of proven field use, MIRAFI® S-Series products provide reliable soil stabilization, efficient drainage, and reduced aggregate consumption, ensuring longer service life and lower environmental impact.

  ---

  Key Features & Advantages

  • Mechanically bonded nonwoven: Delivers high tensile strength and puncture resistance during installation and service.

  • Separation & stabilization: Prevents intermixing of fine subgrade and coarse aggregate, maintaining layer integrity.

  • Filtration & drainage efficiency: Ensures controlled water flow while retaining fine soil particles.

  • Durability: Chemically inert and resistant to biological and alkaline attack.

  • Sustainability: 100 % polypropylene, fully recyclable and environmentally safe.

  • Certified quality: Produced under ASQUAL certification, tested in accordance with EN ISO 10319, EN ISO 11058, EN ISO 12236, and EN ISO 12956.

  ---

  Applications

  • Road and rail subgrade separation and stabilization

  • Working platforms and construction access roads

  • Drainage trenches and leachate collection systems

  • Landfill and reservoir liner protection layers

  • Erosion control and slope stabilization

  • Filtration layers in retaining and embankment structures

  ---

  Performance Summary (S41 Grade)

  Property	Typical Value (S41)	Standard / Unit
  Material	100 % UV-stabilized polypropylene continuous filament	-
  Structure	Mechanically bonded needle-punched nonwoven	-
  Mass per unit area	≈ 150 g/m²	EN ISO 9864
  Thickness (2 kPa)	≈ 1.6 mm	EN ISO 9863-1
  Tensile strength (MD / CMD)	≈ 12 kN/m each direction	EN ISO 10319
  Elongation at break (MD / CMD)	≈ 80 % / 70 %	EN ISO 10319
  CBR puncture resistance	≈ 1.75 kN	EN ISO 12236
  Characteristic opening size (O₉₀)	≈ 110 µm	EN ISO 12956
  Permeability (Δh = 50 mm)	≈ 90 mm/s	EN ISO 11058
  Certification	ASQUAL Certified	-

  (Values per Solmax ASQUAL Technical Data Sheet, Rev 07/2023.)

  ---

  Installation Guidelines (Summary)

  1. Prepare the subgrade: Level surface; remove ruts > 100 mm.

  2. Roll out geotextile: Place directly on the prepared area without tension.

  3. Overlap or weld: Minimum 300 mm overlap (500 mm for soft subgrades); welding recommended for grades ≥ 200 g/m².

  4. Repair damages: Patch with same grade geotextile overlapping ≥ 500 mm.

  5. Place fill: Back-dump aggregate onto the fabric; avoid direct truck traffic.

  6. Spread and compact: Use tracked equipment and vibratory rollers; target rut depth ≤ 30 mm.

  7. Re-grade if required: Fill ruts with fresh aggregate only.

  ---

  Authorized Supply in Africa

  Geosynthetics Africa (Pty) Ltd is an authorized supplier  of Solmax MIRAFI® geotextiles throughout South Africa.


  ---

  MIRAFI® and are registered trademarks of Solmax.
  Builders Merchant (Pty) Ltd is an authorized distributor and installer of Solmax MIRAFI® products across Africa.
  All technical data, brand references, and imagery are used under authorization.
  Geosynthetics Africa does not claim ownership of the MIRAFI® or trademarks.
